T-Manifolds

These T-shape 3 junction fittings allow a variety of conduit size variations. These fittings are designed to snap together over all types of slit and unslit conduit, maintaining maximum conduit bore.
Features:

Compact design - Reducing distance between centres
High pull-off strength – Conduit corrugations sit tightly into joiner junctions
Integral retaining clips - Retains conduit in position during assembly
Internal form of fittings protects cables from abrasion
Internal backstop alleviates any potential problems caused by unevenly cut conduit and ensures correct assembly
All Harnessflex Y-Manifolds can be used with CCSB to further enhance the conduit and connection's tensile and bending performance
Temperature range: Long term: -40°C to +120°C
UV resistance: Very high (Black)
Fire perfomance: Self extinguishing, Low smoke toxicity, Halogen free
Approvals:

CE Mark to the Low Voltage Directive
RoHS Compliant to 2011/65/EU
Conforms with End of Life Vehicle directive (ELV) EU200/53/EC

ABB Harnessflex TPS080808 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 08-08-08 / NW 7.5-7.5-7.5

Part number:: TPS080808
Equates :: 9806082
Color :: Black

Stock:: 852 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.94* /pcs.
From 25 pcs.	€0.62* /pcs.
From 100 pcs.	€0.52* /pcs.
From 1000 pcs.	€0.47* /pcs.

ABB Harnessflex TPS081208 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 08-12-08 / NW 7.5-10-7.5

Part number:: TPS081208
Equates :: 9806180
Color :: Black

Stock:: 947 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.85* /pcs.
From 25 pcs.	€0.57* /pcs.
From 100 pcs.	€0.47* /pcs.
From 1000 pcs.	€0.42* /pcs.

ABB Harnessflex TPS100808 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 10-08-08 / NW 8.5-7.5-7.5

Part number:: TPS100808
Color :: Black
Manufacturer :: ABB

Stock:: 989 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.80* /pcs.
From 25 pcs.	€0.54* /pcs.
From 100 pcs.	€0.44* /pcs.
From 1000 pcs.	€0.40* /pcs.

ABB Harnessflex TPS100810 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 10-08-10 / NW 8.5-7.5-8.5

Part number:: TPS100810
Color :: Black
Manufacturer :: ABB

Stock:: 1002 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€1.03* /pcs.
From 25 pcs.	€0.69* /pcs.
From 100 pcs.	€0.57* /pcs.
From 1000 pcs.	€0.52* /pcs.

ABB Harnessflex TPS101010 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 10-10-10 / NW 8.5-8.5-8.5

Part number:: TPS101010
Equates :: 9806133
Color :: Black

Stock:: 951 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.80* /pcs.
From 25 pcs.	€0.53* /pcs.
From 100 pcs.	€0.44* /pcs.
From 1000 pcs.	€0.40* /pcs.

ABB Harnessflex TPS101012 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 10-10-12 / NW 8.5-8.5-13

Part number:: TPS101012
Equates :: 9806088
Color :: Black

Stock:: 984 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.77* /pcs.
From 25 pcs.	€0.51* /pcs.
From 100 pcs.	€0.42* /pcs.
From 1000 pcs.	€0.38* /pcs.

ABB Harnessflex TPS120808 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 12-08-08 / NW 10-7.5-7.5

Part number:: TPS120808
Equates :: 9806087
Color :: Black

Stock:: 223 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.81* /pcs.
From 25 pcs.	€0.54* /pcs.
From 100 pcs.	€0.44* /pcs.
From 1000 pcs.	€0.40* /pcs.

ABB Harnessflex TPS120812 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 12-08-12 / NW 10-7.5-10

Part number:: TPS120812
Equates :: 9806111
Color :: Black

Stock:: 165 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€1.04* /pcs.
From 25 pcs.	€0.69* /pcs.
From 100 pcs.	€0.57* /pcs.
From 1000 pcs.	€0.52* /pcs.

ABB Harnessflex TPS121010 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 12-10-10 / NW 10-8.5-8.5

Part number:: TPS121010
Equates :: 9806188
Color :: Black

Stock:: 708 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.82* /pcs.
From 25 pcs.	€0.54* /pcs.
From 100 pcs.	€0.45* /pcs.
From 1000 pcs.	€0.41* /pcs.

ABB Harnessflex TPS121012 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 12-10-12 / NW 10-8.5-10

Part number:: TPS121012
Equates :: 9806086
Color :: Black

Stock:: 773 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.93* /pcs.
From 25 pcs.	€0.62* /pcs.
From 100 pcs.	€0.51* /pcs.
From 1000 pcs.	€0.47* /pcs.

ABB Harnessflex TPS121208 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 12-12-08 / NW 10-10-7.5

Part number:: TPS121208
Equates :: 9806097
Color :: Black

Stock:: 766 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.90* /pcs.
From 25 pcs.	€0.60* /pcs.
From 100 pcs.	€0.49* /pcs.
From 1000 pcs.	€0.45* /pcs.

ABB Harnessflex TPS121212 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 12-12-12 / NW 10-10-10

Part number:: TPS121212
Equates :: 9806089
Color :: Black

Stock:: 528 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.65* /pcs.
From 25 pcs.	€0.44* /pcs.
From 100 pcs.	€0.36* /pcs.
From 1000 pcs.	€0.33* /pcs.

ABB Harnessflex TPS121612 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 12-16-12 / NW 10-13-10

Part number:: TPS121612
Equates :: 9806186
Color :: Black

Stock:: 898 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.80* /pcs.
From 25 pcs.	€0.53* /pcs.
From 100 pcs.	€0.44* /pcs.
From 1000 pcs.	€0.40* /pcs.

ABB Harnessflex TPS160808 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-08-08 / NW 13-7.5-7.5

Part number:: TPS160808
Color :: Black
Manufacturer :: ABB

Stock:: 228 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.89* /pcs.
From 25 pcs.	€0.59* /pcs.
From 100 pcs.	€0.49* /pcs.
From 250 pcs.	€0.45* /pcs.

ABB Harnessflex TPS160812 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-08-12 / NW 13-7.5-10

Part number:: TPS160812
Color :: Black
Manufacturer :: ABB

Stock:: 200 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.89* /pcs.
From 25 pcs.	€0.59* /pcs.
From 100 pcs.	€0.49* /pcs.
From 250 pcs.	€0.45* /pcs.

ABB Harnessflex TPS160816 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-08-16 / NW 13-7.5-13

Part number:: TPS160816
Equates :: 9806092
Color :: Black

Stock:: 256 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€1.02* /pcs.
From 25 pcs.	€0.68* /pcs.
From 100 pcs.	€0.56* /pcs.
From 250 pcs.	€0.51* /pcs.

ABB TPS161012 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-10-12 / NW 13-8.5-10

Part number:: TPS161012
Color :: Black
Manufacturer :: ABB

Stock:: 243 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€1.16* /pcs.
From 25 pcs.	€0.78* /pcs.
From 100 pcs.	€0.64* /pcs.
From 250 pcs.	€0.58* /pcs.

ABB Harnessflex TPS161016 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-10-16 / NW 13-8.5-13

Part number:: TPS161016
Equates :: 9806118
Color :: Black

Stock:: 162 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€1.04* /pcs.
From 25 pcs.	€0.69* /pcs.
From 100 pcs.	€0.57* /pcs.
From 250 pcs.	€0.52* /pcs.

ABB Harnessflex TPS161212 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-12-12 / NW 13-10-10

Part number:: TPS161212
Equates :: 9806091
Color :: Black

Stock:: 102 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.89* /pcs.
From 25 pcs.	€0.59* /pcs.
From 100 pcs.	€0.49* /pcs.
From 250 pcs.	€0.45* /pcs.

ABB Harnessflex TPS161216 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-12-16 / NW 13-10-13

Part number:: TPS161216
Equates :: 9806101
Color :: Black

Stock:: 132 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.73* /pcs.
From 25 pcs.	€0.49* /pcs.
From 100 pcs.	€0.40* /pcs.
From 250 pcs.	€0.37* /pcs.

ABB Harnessflex TPS161608 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-16-08 / NW 13-13-7.5

Part number:: TPS161608
Equates :: 9806093
Color :: Black

Stock:: 226 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€0.94* /pcs.
From 25 pcs.	€0.62* /pcs.
From 100 pcs.	€0.52* /pcs.
From 250 pcs.	€0.47* /pcs.

ABB Harnessflex TPS161612 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-16-12 / NW 13-13-10

Part number:: TPS161612
Equates :: 9806104
Color :: Black

Stock:: 149 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€1.06* /pcs.
From 25 pcs.	€0.71* /pcs.
From 100 pcs.	€0.58* /pcs.
From 250 pcs.	€0.53* /pcs.

ABB Harnessflex TPS161616 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-16-16 / NW 13-13-13

Part number:: TPS161616
Equates :: 9806115
Color :: Black

Stock:: 302 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€1.02* /pcs.
From 25 pcs.	€0.68* /pcs.
From 100 pcs.	€0.56* /pcs.
From 250 pcs.	€0.51* /pcs.

ABB TPS162012 - T-Manifold TPS-Typ for Corrugated Tubes Size NC 16-20-12 / NW 13-17-10

Part number:: TPS162012
Color :: Black
Manufacturer :: ABB

Stock:: 227 pcs.
Lead time for more:: 1-4 wk.

From 1 pcs.	€1.17* /pcs.
From 25 pcs.	€0.78* /pcs.
From 100 pcs.	€0.64* /pcs.
From 250 pcs.	€0.59* /pcs.
